EJX110A Differential Pressure Transmitter | Yokogawa

The EJX-A series is Yokogawa’s premium performance line of DPharp transmitters. Released in 2004, it offers the performance and stability needed in demanding applications. The EJX-A series performance makes it the thoroughbred of the DPharp family of pressure transmitters.

The EJX110A is the traditional-mount Differential Pressure Transmitter in the series.

EJX110A features include:

• ± 0.04% Accuracy (0.025% Accuracy option available)
• ± 0.1% per 15 years Stability
• 90 ms Response Time
• 3,600 psi MWP
• Exida and TUV SIL2 / SIL3 Certified
• Local Parameter Setting (LPS)

EJX110A Specification Overview

Refer to the General Specification sheet located under the ‘Downloads’ tab for detailed specifications.

Measurement Types
Primary Variable	Differential Pressure
Secondary Variable	Static Pressure
Reference Accuracy
Primary Variable	±0.04% of Span ±0.025% of Span available
Secondary Variable	±0.2% of Span
Response Time
Primary Variable	90 msec
Secondary Variable	360 msec
Long Term Stability
Primary Variable	±0.1% of URL per 15 years
Over-pressure effect
Primary Variable	±0.03% of URL
Rangeability
Primary Variable	200:1
